Project Description

Magnetic Silica Microspheres

Magnetic silica beads that we can offer are: embedding type and core shell type. The former is prepared by embedding the magnetic nanoparticles(Fe3O4 nanoparticles) in the silica microspheres and the later is by coating silica core with a layer of magnetic particles.

By chemical modification, magnetic silica microspheres can link with various functional groups as well as special antibody, protein, and nucleic acid which make magnetic silica microspheres widely used in the industries of DNA/RNA/ nucleic acid purification, cell screening, immunoassay, clinical diagnosis and other various fields.

The functions of separation and purification make magnetic silica beads essential in the scientific research of medical industry and molecular biology.

1) Magnetic Silica Beads—Embedding type

Magnetic Silica Beads-Embedding type

Appearance

The suspension of silica coated magnetic beads are yellowish-brown. The structure of embedding type magnetic SiO2 microspheres is that Fe3O4 magnetic nanoparticles embedded in the monodisperse silica microspheres. This type of magnetic microspheres is superficially functionalized with rich silanol groups. The dispersant is phosphate buffer. It has good monodispersity and magnetic response. Sedimentation will happen after long time unused. Before use, shake or ultrasonic dispersion is suggested.

Features

  • Strong magnetic response ( Bs 27.2 emu/g )
  • High mechanical and chemical stability
  • 0.1-5 µm are available

Specifications

MatrixSurface GroupsParticle SizeModelUnitW/V
SiO2-NH2200nmEPR-MSEN-0250mg/10ml0.50%
SiO2-NH21umEPR-MSEN-1100mg/10ml1%
SiO2-NH23umEPR-MSEN-3100mg/10ml1%
SiO2-NH25umEPR-MSEN-5100mg/10ml1%
SiO2-NH210umEPR-MSEN-10100mg/10ml1%
SiO2-COOH200nmEPR-MSEC-0250mg/10ml0.50%
SiO2-COOH1umEPR-MSEC-1100mg/10ml1%
SiO2-COOH3umEPR-MSEC-3100mg/10ml1%
SiO2-COOH5umEPR-MSEC-5100mg/10ml1%
SiO2-COOH10umEPR-MSEC-10100mg/10ml1%
SiO2-Epoxy200nmEPR-MSEE-0250mg/10ml0.50%
SiO2-Epoxy1umEPR-MSEE-1100mg/10ml1%
SiO2-Epoxy3umEPR-MSEE-3100mg/10ml1%
SiO2-Epoxy5umEPR-MSEE-5100mg/10ml1%
SiO2-Epoxy10umEPR-MSEE-10100mg/10ml1%
SiO2-SiOH200nmEPR-MSES-0250mg/10ml0.50%
SiO2-SiOH1umEPR-MSES-1100mg/10ml1%
SiO2-SiOH3umEPR-MSES-3100mg/10ml1%
SiO2-SiOH5umEPR-MSES-5100mg/10ml1%
SiO2-SiOH10umEPR-MSES-10100mg/10ml1%

2) Magnetic Silica Beads-Core shell type

Appearance

The core shell type magnetic silica microspheres are brown suspension. The structure of core shell type is with monodisperse silica microspheres coated by a layer of magnetic nanoparticles. The dispersant is phosphate buffer. It has good mono dispersity and magnetic response. Sedimentation will happen after long time unused. Before use, shake or ultrasonic dispersion is suggested.

Features

  • Superparamagnetic microspheres
  • Better monodispersity
  • 0.1um-5um are available

Specifications

MatrixSurface GroupsParticle SizeModelUnitW/V
SiO2-NH2200nmEPR-MSCN-0250mg/10ml0.50%
SiO2-NH21umEPR-MSCN-1100mg/10ml1%
SiO2-NH23umEPR-MSCN-3100mg/10ml1%
SiO2-NH25umEPR-MSCN-5100mg/10ml1%
SiO2-NH210umEPR-MSCN-10100mg/10ml1%
SiO2-COOH200nmEPR-MSCC-0250mg/10ml0.50%
SiO2-COOH1umEPR-MSCC-1100mg/10ml1%
SiO2-COOH3umEPR-MSCC-3100mg/10ml1%
SiO2-COOH5umEPR-MSCC-5100mg/10ml1%
SiO2-COOH10umEPR-MSCC-10100mg/10ml1%
SiO2-Epoxy200nmEPR-MSCE-0250mg/10ml0.50%
SiO2-Epoxy1umEPR-MSCE-1100mg/10ml1%
SiO2-Epoxy3umEPR-MSCE-3100mg/10ml1%
SiO2-Epoxy5umEPR-MSCE-5100mg/10ml1%
SiO2-Epoxy10umEPR-MSCE-10100mg/10ml1%
SiO2-SiOH200nmEPR-MSCS-0250mg/10ml0.50%
SiO2-SiOH1umEPR-MSCS-1100mg/10ml1%
SiO2-SiOH3umEPR-MSCS-3100mg/10ml1%
SiO2-SiOH5umEPR-MSCS-5100mg/10ml1%
SiO2-SiOH10umEPR-MSCS-10100mg/10ml1%
